Flagship Software

MessMAX® – One Software for All Devices

Measure – Control – Evaluate

MessMAX® is the universal measurement software for data acquisition, evaluation and the control of actuators. Intuitive to operate, no programming required – fully compatible with the entire Burat & Klein hardware portfolio and external devices via Ethernet, USB, CAN bus and Modbus TCP.

A single software for all B&K MessBOXes, TeleInspektors and external devices
No programming required – fully parameterisable
Available as Professional and Network version (64 bit)
Web connectivity for remote maintenance, data display and remote control
Now with Modbus TCP – evaluate measured values from Modbus devices directly

MessMAX® System Overview

Measure and Visualise

MessMAX® visualisation – time chart, FFT, XY plot

Configurable visualisations
Intuitive user interface – no programming required
XY plot
FFT analysis
Time chart
Overlay of measurement files
Dynamic single, series and ring buffer measurement
Event channels for signal or alarm output

Calculate and Evaluate

MessMAX® calculation and evaluation – FFT, curve smoothing, peak values

Online calculation of measured values
Online calculation of logical operations
Curve smoothing
Automatic peak value detection
Measurement point labelling
Simultaneous acquisition of all incoming measured values
Export of results as measurement report including graphics

Software

MessMAX® – Technical Data

System requirements and hardware support

MessMAX® runs on modern Windows 11 systems and supports the entire Burat & Klein hardware portfolio as well as third-party devices via Ethernet, USB, CAN bus and Modbus TCP.

Technical Data

Overview
Available Versions	Professional (64 bit) / Network (64 bit)
Max. Measurement Channels	256
Max. Total Sampling Rate	100 kHz
Web Connectivity	Remote maintenance for data display / control and configuration of the measurement application
System Requirements
Processor	Minimum: Intel® Core™ ab 8. Generation oder AMD-Processoren ab ca. 2018
Memory (RAM)	Minimum 4 GB / Recommended 8 GB
Screen Resolution	Minimum 1280 × 1024 px / Recommended 1920 × 1080 px (Full HD)
Operating System	Microsoft® Windows® 11 (Build 23H2, 24H2, 25H2 and newer) Windows® 10 is no longer developed or tested for functionality ▶ Windows 11 support only from MessMAX version 3.10.40 ▶ Windows® on ARM is currently not supported
General Recommendation	Microsoft® Windows® Professional / Hardware for business use (workstations or business notebooks)
Measurement Hardware Support
Compact Measurement Devices	Interchangeable measurement amplifiers for all common sensors
Electrical Power Meters	Zimmer (LMG 95 / 450 / 500) / Yokogawa (WT300, WT333, WT1800, WT3000)
Supported Interfaces	Ethernet / USB / CAN bus / Modbus TCP
Import / Export	ASCII file / CSV / Custom formats on request
